| Specification | Details |
|---|---|
| Brand | INSIZE |
| Model | 3282-100 |
| Product Type | Disk Micrometer |
| Measuring Range | 75–100 mm |
| Graduation | 0.01 mm |
| Accuracy | 5 µm |
| Parallelism | 5 µm |
| Measuring Type | Mechanical / Analogue |
| Thimble Type | Ratchet Stop |
The INSIZE 3282-100 Disk Micrometer is a precision mechanical measuring instrument designed for measuring the root tangent length of gears and other suitable components requiring disk-type measuring faces. It provides a 75–100 mm measuring range, 0.01 mm graduation, and 5 µm accuracy, making it suitable for gear inspection, machining quality control, and dimensional measurement. The micrometer features a ratchet stop for controlled measuring force and is supplied with a setting standard for the applicable range. The 3282-100 is suitable for CNC machining, gear manufacturing, tool-room inspection, and general engineering applications.
Key Features
1. 75–100mm Measuring Range
The 3282-100 provides a 75–100 mm measuring range, making it suitable for measuring larger gear dimensions and compatible components requiring disk-type measuring contact.
2. 0.01mm Graduation
The micrometer provides 0.01 mm graduation, allowing detailed mechanical readings for gear inspection, machining, and dimensional quality control.
3. 5µm Accuracy
The 3282-100 is specified with 5 µm accuracy, providing suitable precision for dimensional inspection and gear measurement applications.
4. Disk Measuring Faces
The disk-type measuring arrangement is designed particularly for root tangent length measurement of gears, providing a specialized contact geometry for suitable gear inspection applications.
5. Ratchet Stop & Setting Standard
The ratchet stop helps provide controlled measuring force, while the 3282 series is supplied with setting standards, supporting setup and calibration for the applicable measuring range.
