| Specification | Details |
|---|---|
| Brand | INSIZE |
| Model | 3353-100AWL |
| Product Type | Digital Disk Micrometer / Snap Gauge |
| Measuring Range | 75–100 mm / 3–3.95" |
| Resolution | 0.0002 / 0.001 / 0.01 mm |
| Accuracy | 5 µm |
| Repeatability | 1 µm |
| Parallelism | 5 µm |
| Spindle Type | Non-Rotating |
| Measuring Faces | Carbide |
The INSIZE 3353-100AWL Digital Disk Micrometer / Snap Gauge is a high-precision digital measuring instrument designed for measuring the root tangent length of gears and suitable external dimensions. It provides a 75–100 mm / 3–3.95 inch measuring range, adjustable resolution down to 0.0002 mm / 0.00001 inch, 5 µm accuracy, 1 µm repeatability, and 5 µm parallelism. The instrument features carbide measuring faces, a non-rotating spindle, IP65 protection, and built-in wireless data transmission, making it suitable for CNC machining, gear inspection, manufacturing quality control, and precision metrology.
Key Features
1. 75–100mm Measuring Range
The 3353-100AWL provides a 75–100 mm measuring range, equivalent to approximately 3–3.95 inches, making it suitable for larger gear and component inspection applications.
2. Ultra-Fine 0.0002mm Resolution
The instrument offers adjustable resolution of 0.0002 mm / 0.00001 inch, with selectable 0.001 mm and 0.01 mm resolutions. This provides high-resolution digital measurement for precision inspection.
3. Accurate & Repeatable Measurement
INSIZE specifies 5 µm accuracy, 1 µm repeatability, and 5 µm parallelism for the 3353-100AWL. These specifications support precision dimensional inspection and quality-control applications.
4. Carbide Measuring Faces & Non-Rotating Spindle
The 3353 series features carbide measuring faces and a non-rotating spindle. One complete sleeve rotation provides 5 mm spindle feed, while pressing the fork retracts the spindle by 3 mm, helping provide efficient measurement operation.
5. Built-In Wireless Data Output
The AWL version incorporates built-in wireless data transmission, supporting convenient transfer of measurement data when used with a compatible receiver. The instrument also supports functions including tolerance, data preset, data hold, measuring-direction change, maximum/minimum measurement, zero, mm/inch conversion, and adjustable resolution.
