Techno MOUNTING RB 50 DNC Pneumatic Cylinder Series

The Techno MOUNTING RB 50 DNC Pneumatic Cylinder Series is an advanced pneumatic actuator designed to provide high-performance, reliable, and precise linear motion for a wide range of industrial and automation applications. Featuring a 50 mm bore size, this cylinder delivers a balanced combination of force, speed, and precision, making it ideal for medium to heavy-duty applications where consistent performance is essential. The RB 50 DNC series excels in environments such as material handling, packaging, machine tools, automation systems, and other industrial machinery that require efficient actuation.

This cylinder operates using compressed air to produce linear motion, offering fast response times and high cycle rates. The RB 50 DNC series is known for its durability and versatility, capable of handling high workloads with minimal maintenance. Designed with flexible mounting options, it allows for easy installation and integration into various systems, ensuring adaptability to different machine configurations. The robust construction and corrosion-resistant finish ensure the cylinder performs optimally in demanding environments, while the customizable stroke length ensures precise control over the range of movement for each specific application.

Key Features:

1. Cylinder Size (50 mm Bore):
   The 50 mm bore size of the RB 50 DNC pneumatic cylinder delivers a strong force output, making it suitable for medium to heavy-duty tasks that require a higher force than smaller cylinders. It is ideal for applications involving lifting, clamping, positioning, and pressing, where higher power and precision are necessary.
2. DNC Series Design:
   The RB 50 DNC series is part of the renowned DNC line, known for its robust construction and versatility. It is engineered to operate efficiently under high cycle rates and demanding conditions, ensuring long-term reliability even with minimal maintenance requirements. The DNC series is trusted for its ability to perform in both high- and low-cycle applications.
3. RB Mounting Configuration:
   The RB mounting style offers flexible and secure mounting options, which allow the cylinder to be easily integrated into various industrial systems. Whether the system requires horizontal, vertical, or custom mounting positions, the RB mounting configuration ensures the cylinder adapts to a wide range of machine layouts and installation needs.
4. Pneumatic Actuation:
   The RB 50 DNC cylinder is powered by compressed air, providing fast, energy-efficient linear motion with quick response times. Pneumatic cylinders are ideal for high-speed, high-cycle applications due to their ability to generate rapid movement with lower energy consumption compared to other types of actuators.
5. Durable Construction:
   Constructed from high-strength materials like anodized aluminum and steel, the RB 50 DNC pneumatic cylinder is built to withstand harsh environments and extended use. The cylinder features a corrosion-resistant finish that protects it from moisture, dust, and chemical exposure, ensuring long-lasting performance even in challenging conditions.
6. Customizable Stroke Length:
   The RB 50 DNC series offers customizable stroke lengths to suit specific application needs. Whether a short or extended stroke is required, the cylinder can be configured to provide the exact range of motion needed for the application, offering flexibility for a variety of tasks.
7. Corrosion-Resistant Finish:
   The corrosion-resistant coating of the RB 50 DNC cylinder ensures that it remains operational even in environments with exposure to humidity, chemicals, and other corrosive substances. This feature helps to reduce maintenance needs and extend the cylinder’s lifespan.
8. Low Maintenance and Easy Integration:
   The RB 50 DNC cylinder is designed for minimal maintenance, ensuring reduced downtime and operational efficiency. Its simple design and flexible mounting options make it easy to integrate into existing systems, making installation and setup quick and straightforward.

Applications:

The Techno MOUNTING RB 50 DNC Pneumatic Cylinder Series is highly suited for medium to heavy-duty applications in industries that require reliable, high-speed, and precise motion control. Common applications include:

• Material Handling: Used for lifting, pressing, clamping, and positioning of materials, parts, or tools in manufacturing and warehouse systems.
• Machine Tools: Ideal for clamping, feeding, and positioning in CNC machines, presses, and other industrial equipment.
• Packaging: Employed in packaging systems for tasks like sealing, pressing, or moving goods along production lines.
• Automation Systems: Applied in robotic arms, conveyor systems, and other automated machinery that require accurate and reliable linear motion for various assembly or sorting tasks.
• Assembly Lines: Used in assembly lines for repetitive tasks such as picking, positioning, and placing parts in machinery or packaging.
• Testing Equipment: Used in precision testing and measurement systems where high-performance motion is necessary.

Benefits:

• High Force Output: With a 50 mm bore size, the RB 50 DNC cylinder provides a substantial force for applications that require more power, such as material handling and machine tools, while maintaining precision.
• Energy Efficiency: The pneumatic actuation system ensures efficient energy usage, providing rapid and reliable motion with minimal energy consumption.
• Durability and Longevity: Built with high-quality materials and a corrosion-resistant finish, the RB 50 DNC series is designed to handle demanding conditions and has a long service life, reducing the need for frequent replacements and minimizing downtime.
• Flexible Mounting Options: The RB mounting style provides a range of mounting configurations, offering greater flexibility in installation for diverse systems and applications.
• Customizable Stroke: The stroke length can be tailored to specific application needs, providing the ideal range of motion for various tasks.
• Minimal Maintenance: Designed for long-term, trouble-free operation, the RB 50 DNC cylinder requires minimal maintenance, helping reduce operational costs and improve efficiency.
• Simple Integration: Its flexible design and standardized mounting options make the RB 50 DNC cylinder easy to integrate into existing systems, reducing setup time and costs.

Specifications:

• Type: Pneumatic Cylinder (Actuator)
• Bore Diameter: 50 mm
• Series: DNC (Durable and Versatile Pneumatic Cylinder Series)
• Mounting Style: RB (Flexible, multiple mounting options)
• Stroke Length: Customizable to meet application needs
• Material: Anodized aluminum and steel for durability and corrosion resistance
• Operating Medium: Compressed air
• Operating Pressure: Typically 6-10 bar (varies by application and system design)
• Temperature Range: Operates effectively within a temperature range of -10°C to 80°C, depending on seals and materials.

The Techno MOUNTING RB 50 DNC Pneumatic Cylinder Series offers a reliable and efficient solution for industrial and automation applications requiring high force, speed, and precision. With its flexible mounting options, customizable stroke lengths, and durable design, it is an ideal choice for a wide variety of medium to heavy-duty tasks, ensuring high performance and minimal downtime.
