| Brand | Meco |
| Model | HIT 5 - 1 |
| Product Type | Analog Insulation Tester (Hand Cranking Type) |
| Test Voltage | 500V DC |
| Insulation Resistance Range | 0–100 MΩ |
| Display Type | Analog |
| Accuracy | ±1% Full Scale |
| Scale Length | Approx. 65 mm |
| Operating Method | Manual Hand Cranking |
| Cranking Speed | Approx. 120 RPM |
| Measurement Range | 10% to 100% of Insulation Resistance Range |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -10°C to 60°C |
| Relative Humidity | Maximum 80% |
| Insulation Resistance Between Circuit & Case | More than 20 MΩ at 500V |
| Accessories | Test & Calibration Certificate, Crocodile Leads, Carrying Case, Instruction Manual |
| Weight | 1 kg |
| Dimensions (L x W x H) | 15 x 21 x 12 cm |
The Meco HIT 5-1 Analog Insulation Tester is a rugged and reliable hand cranking type insulation resistance measuring instrument designed for electricians, maintenance engineers, and industrial professionals. It is specially developed for checking insulation quality in electrical equipment and installations where accurate and dependable insulation measurement is required. The tester operates with a 500V DC test voltage and provides an insulation resistance measurement range of 0–100 MΩ, making it suitable for a wide variety of low and medium voltage electrical applications.
The Meco HIT 5-1 is ideal for insulation resistance testing of:
Electrical motors and transformers
Generators and industrial machines
Electrical panels and switchgear
Power and distribution cables
Communication and telecom cables
Commercial and residential electrical installations
Household appliances such as washing machines, mixers, and toasters
The instrument features a single-person hand-driven mechanism with an approximate cranking speed of 120 RPM, providing a steady output voltage for accurate insulation measurement. Its 65 mm analog scale allows easy reading of insulation resistance values, while the high accuracy of ±1% Full Scale (FS) ensures dependable test results.
Designed for harsh industrial environments, the MC HIT 5-1 comes with a rugged plastic/metal protective case to prevent moisture ingress and improve durability. The built-in Guard Terminal helps reduce measurement errors caused by surface leakage currents, improving testing reliability. It measures insulation resistance effectively from 10% to 100% of the specified range.
The Meco HIT 5-1 is supplied with essential accessories including a test and calibration certificate, crocodile/alligator test leads, carrying case, and instruction manual, making it ready for professional insulation testing applications. It is widely used in electrical maintenance, preventive inspections, commissioning, and troubleshooting of electrical systems.
Key Features:
500V DC insulation test voltage
Insulation resistance range:
0–100 MΩHand cranking type operation
Single-person hand-driven design
High accuracy:
±1% Full ScaleApprox. 120 RPM cranking speed
Approx. 65 mm analog scale length
Steady and accurate readings
Guard terminal to reduce surface leakage errors
Rugged plastic/metal moisture-resistant housing
Suitable for motors, transformers, generators, cables, panels, and machines
Supplied with carrying case, test leads, calibration certificate, and manual
