| Model | MECO PM-VAC-5R |
| Display | 5 Digit LCD with Backlight |
| Measurement Type | AC True RMS Voltage |
| Voltage Ranges | 200 mV, 2 V, 20 V, 200 V, 750 V |
| Accuracy | ±(0.5% Reading + 3 Digits) |
| Sampling Rate | 3 Samples/Second |
| Power Supply | 4 × 1.5V AA Batteries |
| Optional Power | 6V DC Adapter |
| Connectivity | USB |
| Functions | Data Hold, Auto Power Off, Overload & Low Battery Indication |
| Protection | Overload Protection |
| Construction | Rugged Portable Body with Tilt Stand |
| Weight | 1 kg |
| Dimensions (L x W x H) | 24 x 17 x 8 cm |
The MECO PM-VAC-5R Digital Multi-Range Portable Meter is a professional-grade 5-digit AC True RMS portable voltmeter engineered for precise and reliable AC voltage measurement. Designed using advanced microcontroller technology and SMT construction, the instrument delivers highly accurate readings without the inaccuracies associated with moving parts.
Its True RMS measurement capability ensures accurate voltage readings even for distorted or non-sinusoidal waveforms, making it suitable for industrial electrical systems, laboratories, calibration facilities, engineering colleges, maintenance departments, and research applications.
The meter offers five selectable voltage ranges:
0–200 mV
0–2 V
0–20 V
0–200 V
0–750 V AC
The bright 5-digit LCD display with backlight provides excellent readability in both bright and low-light environments. Additional functions such as Data Hold, Auto Power Off, Low Battery Indication, Overload Indication, and USB connectivity improve usability and productivity during testing and documentation.
Built with a strong rugged enclosure and an integrated tilt stand, the PM-VAC-5R is designed for long-term professional use in demanding environments. Its compact construction allows comfortable bench-top operation as well as easy portability for field measurements. The instrument is supplied with test leads, batteries, instruction manual, and a calibration certificate traceable to NABL standards.
Key Features:
- 5-digit AC True RMS Digital Voltmeter
- Class 0.5 high measurement accuracy
- Five AC voltage ranges up to 750 V
- Bright backlit LCD display
- USB interface for data transfer
- Data Hold function
- Auto Power Off
- Low Battery indication
- Overload indication and protection
- Rugged portable housing with tilt stand
- Microcontroller-based design with no moving parts
- Suitable for laboratory, industrial, educational, and field applications
- Calibration certificate traceable to NABL laboratory included.
The MECO PM-VAC-5R Digital Multi-Range Portable Meter is a high-precision 5-digit AC True RMS (TRMS) multirange voltmeter designed for laboratories, industrial testing, workshops, educational institutions, and field measurement applications. It features five voltage ranges, Class 0.5 accuracy, a backlit LCD display, USB connectivity, data hold, overload protection, and a rugged portable design with a convenient tilt stand.
