| Model | MECO PM-VDC-5R |
| Display | 5 Digit LCD with Backlight |
| Measurement Type | DC Voltage |
| Voltage Ranges | 200 mV, 2 V, 20 V, 200 V, 1000 V |
| Accuracy | ±(0.5% Reading + 3 Digits) |
| Resolution | 0.0001 to 1 Count (Depending on Range) |
| Sampling Rate | 3 Samples/Second |
| Power Supply | 4 × 1.5V AA Batteries |
| Optional Supply | 6V DC Adapter |
| USB Interface | Yes |
| Functions | Data Hold, Auto Power Off, Low Battery & Overload Indication |
| Maximum Overload | 1.2 Times Continuous |
| Operating Temperature | 0°C to 50°C |
| Weight | 1 kg |
| Dimensions (L x W x H) | 24 x 17 x 8 cm |
The MECO PM-VDC-5R Digital Multi-Range Portable Meter is a professional-grade digital DC voltmeter engineered to provide highly accurate and stable voltage measurements across multiple ranges. Built using advanced microcontroller technology with SMT construction, the instrument eliminates moving parts, ensuring long-term reliability, durability, and consistent measurement accuracy.
Designed for continuous DC voltage monitoring, the PM-VDC-5R offers five selectable voltage ranges:
0–200 mV
0–2 V
0–20 V
0–200 V
0–1000 V DC
Its 5-digit LCD display with bright backlight provides clear visibility under various lighting conditions, while the Class 0.5 accuracy ensures dependable readings for precision testing and calibration tasks.
The instrument includes advanced user-friendly functions such as Data Hold, Auto Power Off, Low Battery Indication, Overload Indication, and a USB interface for transferring measurement data to a computer (optional software supported). The sturdy portable housing features an integrated tilt stand, making it ideal for bench-top operation as well as field measurements.
Suitable for laboratories, engineering colleges, production facilities, maintenance departments, calibration centers, and quality control applications, the PM-VDC-5R serves as an excellent secondary standard meter for verification and routine electrical measurements.
Key Features:
- High-precision 5-digit DC Digital Voltmeter
- Five DC voltage measurement ranges up to 1000 V
- Precision Class 0.5 accuracy
- Bright backlit LCD display
- Microcontroller-based design with no moving parts
- USB connectivity for data transfer
- Data Hold function
- Auto Power Off
- Low Battery indication
- Overload indication and protection
- Strong rugged casing with tilt stand
- Ideal for laboratories, industries, educational institutes, and field testing
- Calibration certificate traceable to NABL laboratory included.
