NKP 1/8 x 28 BSPT 1.1/2 Inch Dia Carbon Steel Circular Dies

The NKP 1/8 x 28 BSPT 1.1/2 Inch Dia Carbon Steel Circular Dies are high-performance, durable threading tools designed for cutting BSPT (British Standard Pipe Tapered) threads on 1/8-inch diameter pipes or rods. Made from carbon steel, these circular dies provide high accuracy, reliability, and long-lasting performance in various industrial applications where secure, leak-proof connections are required. Below is a detailed breakdown of the key features and specifications:

Key Features & Specifications:

1. NKP (Brand/Type)

• NKP refers to the brand or product type, recognized for producing precision-engineered threading tools that offer excellent performance and durability across various industrial sectors. NKP tools are ideal for applications requiring high levels of accuracy and reliability.

2. 1/8 x 28 BSPT

• 1/8 x 28 BSPT describes the size and thread type of the die:
  • 1/8″ refers to the diameter of the pipe or rod being threaded, which is 1/8 inch (approximately 3.175 mm).
  • 28 BSPT indicates the BSPT thread specifications with 28 threads per inch (TPI). The BSPT (British Standard Pipe Tapered) threads are specifically designed with a taper to ensure a tight seal when threaded components are connected. The 28 TPI provides a fine pitch, allowing for precise and consistent threads.

3. 1.1/2 Inch Dia

• The 1.1/2-inch diameter (approximately 38.1 mm) refers to the diameter of the circular die. This die size is designed to efficiently accommodate the cutting of 1/8-inch BSPT threads on pipes and rods while ensuring stability and precision during the threading process. The larger diameter of the die ensures that the threading operation is smooth and uniform.

4. Carbon Steel Construction

• The die is made from carbon steel, a material known for its strength, durability, and resilience. Carbon steel ensures the die can handle the mechanical stresses involved in threading, maintaining its sharpness and performance even with extended use. The material also provides resistance to corrosion, making it well-suited for industrial environments.

5. Circular Dies

• Circular dies are used for cutting external threads on cylindrical workpieces such as pipes, rods, and bolts. The die is typically mounted in a die stock or holder, which allows it to rotate while cutting the threads into the workpiece. The circular design ensures that the die produces consistent, smooth threads, guaranteeing high-quality and uniform results.

Applications:

• Pipe Threading: The NKP 1/8 x 28 BSPT 1.1/2 Inch Dia Carbon Steel Circular Die is ideal for cutting BSPT threads on 1/8-inch diameter pipes used in plumbing, gas systems, hydraulic systems, and pneumatic systems. The BSPT threads provide a tight, leak-proof seal when connected to BSPT fittings.
• Hydraulic and Pneumatic Systems: This die is frequently used for creating threads in hydraulic and pneumatic systems where tapered threads are essential for high-pressure, leak-proof connections.
• Industrial & Mechanical Work: Suitable for threading components in machinery, mechanical systems, and other industrial applications, where precision and secure connections are necessary.
• Fluid and Gas Systems: The BSPT threads are specifically designed for fluid and gas systems, ensuring the threads provide tight, reliable connections that prevent leaks and ensure system integrity.

Key Features:

• Threading Capacity: The 1.1/2-inch die diameter ensures the die can efficiently cut 1/8-inch BSPT threads on pipes with the appropriate 28 TPI BSPT threads. The larger die diameter provides a stable and consistent threading process, ensuring accuracy in every cut.
• Durability: Carbon steel construction makes this die highly durable, capable of withstanding repeated use without losing its sharpness or effectiveness. The material's wear resistance ensures that the die can handle the stresses of threading operations, maintaining a high level of performance.
• Precision: With 28 TPI BSPT threads, this die ensures fine, precise threading that meets BSPT standards for a secure, leak-proof seal in industrial applications.
• Versatility: This die is highly versatile and can be used across various industries, including plumbing, hydraulics, mechanics, and gas systems, to create high-quality threads for secure, leak-proof connections.

Conclusion:

The NKP 1/8 x 28 BSPT 1.1/2 Inch Dia Carbon Steel Circular Die is a high-quality, durable, and precise threading tool designed for cutting BSPT threads on 1/8-inch diameter pipes. Made from carbon steel, it offers excellent durability and wear resistance, ensuring long-lasting performance even in demanding applications. The 28 TPI BSPT threads provide precise, fine threads, ideal for creating secure, leak-proof connections in plumbing, gas systems, hydraulic systems, and mechanical systems. This die is a reliable solution for any industry requiring high-quality and precise threading for a range of piping and mechanical applications.
