Techno CDRB2BW-30 90 Pneumatic Cylinder

The Techno CDRB2BW-30 90 Pneumatic Cylinder is a robust, double-acting actuator designed to provide precise and controlled linear motion across a variety of industrial and automation applications. Featuring a 30mm bore size and a 90mm stroke length, this cylinder delivers efficient force and motion control in medium-duty environments. The design prioritizes durability, smooth operation, and versatility, making it suitable for applications in material handling, robotics, automation, and machine tools.

Key Features & Specifications:

1. Bore Size:
   • The bore size of the Techno CDRB2BW-30 90 is 30 mm, which is a medium-sized bore suitable for moderate force output. This size offers an optimal balance between compactness and performance, delivering the necessary force for many applications without taking up excessive space.
   • The 30mm bore size makes it ideal for tasks requiring controlled movement, such as positioning, clamping, and light to medium-duty pushing/pulling operations.
2. Stroke Length:
   • The stroke length of 90 mm indicates the maximum distance the piston can travel between its fully extended and fully retracted positions.
   • This stroke length is appropriate for applications where short to medium travel is required, making it versatile for various automation and industrial applications that need moderate movement in tight spaces.
3. Double-Acting Design:
   • The CDRB2BW-30 90 is a double-acting cylinder, meaning it uses compressed air to move the piston in both directions (extension and retraction). This provides precise control and flexibility, as both movements are powered, ensuring the cylinder is efficient in both directions.
   • This design also contributes to higher performance in automated systems where both extension and retraction need to be precisely controlled.
4. Operating Pressure:
   • The CDRB2BW-30 90 operates within an operating pressure range of 1 to 8 bars (14.5 psi to 116 psi). This makes it suitable for various applications where moderate force and precision are required without requiring extremely high-pressure systems.
   • The working pressure range is ideal for use in standard industrial environments, ensuring reliable operation while maintaining energy efficiency.
5. Body Construction:
   • The body of the CDRB2BW-30 90 cylinder is made from anodized aluminum, known for its excellent strength-to-weight ratio, corrosion resistance, and lightweight properties.
   • The anodized aluminum finish also ensures enhanced resistance to wear and abrasion, making it durable in challenging environments and increasing the lifespan of the cylinder.
6. Piston Rod:
   • The piston rod is made from high-strength stainless steel, providing excellent durability and resistance to wear and corrosion. Stainless steel is highly resistant to rust, abrasion, and mechanical stresses, ensuring smooth operation throughout the life of the cylinder.
   • The piston rod is critical for converting the force generated by the compressed air into linear mechanical movement, ensuring effective and reliable performance.
7. Temperature Range:
   • The CDRB2BW-30 90 operates effectively in a temperature range of -20°C to 80°C (-4°F to 176°F). This broad range allows the cylinder to be used in a variety of industrial and automation environments, from cold storage facilities to high-temperature production areas, without sacrificing performance.
   • This temperature tolerance ensures reliability in diverse conditions.
8. Mounting Options:
   • The Techno CDRB2BW-30 90 cylinder offers multiple mounting options such as foot mounting, flange mounting, and through-hole mounting. This provides flexibility for installation in various machine and automation setups.
   • Its versatile mounting options ensure that the cylinder can be integrated easily into a wide variety of applications, whether the system has space constraints or specific mounting needs.
9. Seal Design:
   • The CDRB2BW-30 90 features high-quality seals designed to prevent air leakage, ensuring efficient operation. These seals help maintain consistent internal pressure, reduce energy loss, and enhance overall efficiency.
   • The seals also help to protect the internal components from contamination, ensuring smooth piston movement and longer operational life.
10. Performance Features:
    • The low-friction design of the cylinder ensures smooth, consistent movement with minimal wear, contributing to enhanced durability and extended life.
    • The piston seals work effectively to reduce friction, further improving the overall performance of the cylinder.
    • The cylinder is engineered for high repeatability and precision, ensuring consistent performance in applications that require exact positioning or motion control.
11. Applications:
    • Automation Systems: The Techno CDRB2BW-30 90 is ideal for use in robotic arms, pick-and-place systems, assembly lines, and other automated processes where precise, controlled linear motion is required.
    • Material Handling: Commonly used in conveyor systems, sorting systems, and packaging machinery, where the cylinder performs tasks like pushing, pulling, or positioning components efficiently.
    • Machine Tools: Frequently integrated into machine tools for tasks like clamping, feeding, or positioning workpieces in manufacturing or processing environments.
    • Industrial Equipment: Can be used in various industrial equipment, including presses, lifts, and other machinery that require reliable, controlled movement.
12. Auto-Switch Compatibility:
    • The CDRB2BW-30 90 is compatible with auto-switches, which can detect the position of the piston (whether it is fully extended or retracted). This feature provides valuable feedback for automated systems to control processes more effectively.
    • The use of auto-switches enhances process automation, improving the efficiency and reliability of the overall system.
13. Lubrication:
    • The CDRB2BW-30 90 cylinder is designed for self-lubricating operation, reducing the need for constant maintenance. However, periodic lubrication and maintenance are recommended to ensure smooth operation and extend the life of the cylinder.
    • Proper lubrication helps to minimize friction and wear, ensuring the cylinder continues to operate at its best throughout its service life.

Conclusion:

The Techno CDRB2BW-30 90 Pneumatic Cylinder is an efficient, versatile, and durable solution for medium-duty applications requiring precise linear motion. With a 30mm bore size, 90mm stroke length, and double-acting design, it provides smooth, reliable performance for automation, material handling, and machine tool applications. Its anodized aluminum body, stainless steel piston rod, and various mounting options ensure that it is both long-lasting and adaptable to a range of industrial environments. Whether in robotics, conveying systems, or presses, this cylinder offers controlled movement, efficiency, and precision across a wide variety of applications.
