Techno CDRQ2B 15 X 180 Pneumatic Cylinder

The Techno CDRQ2B 15 X 180 Pneumatic Cylinder is a double-acting pneumatic actuator designed to provide precise and reliable linear motion for light to medium-duty applications. With a 15 mm bore and 180 mm stroke, this cylinder is engineered to handle tasks that require moderate force and longer travel distances. It uses compressed air for both extension and retraction, delivering smooth, controlled movement in both directions, making it highly suitable for a wide range of industrial uses.

1. General Overview:

• Type: Pneumatic Cylinder (Double-Acting)
• Series: CDRQ2B
• Bore Size: 15 mm
• Stroke Length: 180 mm
• Action Type: Double-Acting
• Design: Compact, reliable, and efficient, ideal for various industrial applications.

2. Detailed Breakdown of Specifications:

a. Bore Size (15 mm):

• The 15 mm bore size is perfect for moderate-force applications, where power is needed but space is limited. This size provides sufficient force for lighter to medium tasks while maintaining a compact form, ideal for installations in smaller spaces or systems where size constraints are critical.

b. Stroke Length (180 mm):

• The 180 mm stroke allows for a longer travel distance, which is necessary for tasks that require movement over a larger range. This makes the CDRQ2B 15 X 180 suitable for tasks that need significant linear displacement, such as in automated material handling, positioning systems, and pressing operations.

c. Double-Acting Cylinder (D):

• The double-acting design utilizes compressed air for both extension and retraction, ensuring smooth and reliable operation in both directions. This eliminates the need for external spring mechanisms, increasing efficiency and cycle time while ensuring constant and consistent performance, especially in high-demand environments.

3. Key Features and Benefits:

• Moderate Force Output: The 15 mm bore provides sufficient force for light to moderate-duty tasks, making it ideal for positioning, sorting, and pressing tasks in various industries. Despite its small size, the cylinder delivers the necessary performance for lighter material handling or automation tasks.
• Long Stroke: The 180 mm stroke provides the necessary movement for applications requiring extended travel distance. This makes the cylinder ideal for conveyor systems, pick-and-place applications, or any system where precise, longer linear movement is required.
• Double-Acting Design: The double-acting mechanism ensures that the cylinder operates efficiently, using compressed air to extend and retract the piston. This design results in faster cycle times and a more reliable operation, ensuring consistent performance without relying on springs or other retraction systems.
• Durable Construction: The CDRQ2B 15 X 180 is built with high-quality materials, including an anodized aluminum body and hardened steel piston rod, making it resistant to wear and corrosion. This durable construction ensures that the cylinder can withstand demanding environments and high-cycle tasks, providing long-term reliability.
• Energy Efficiency: The double-acting design ensures efficient use of compressed air for both actions, making it an energy-efficient solution. This leads to lower operational costs and sustainable operation over long periods, especially in systems with high-frequency cycles.
• Compact and Space-Saving: The 15 mm bore and 180 mm stroke offer a compact design that is perfect for integration into systems with space limitations. Despite its small size, the cylinder offers long travel distance and reliable force output, making it ideal for use in compact systems.

4. Applications:

• Automation Systems: The CDRQ2B 15 X 180 is widely used in automated production lines, pick-and-place applications, and positioning systems, where precision and repeatability are essential for moving parts and materials in controlled environments.
• Material Handling: Ideal for light material handling and sorting applications, it is perfect for moving small to medium-weight components or for positioning tasks in assembly lines or conveyor systems.
• Pressing and Forming: Suitable for light pressing, aligning, or positioning applications, particularly in industries like electronics, automotive, or food packaging, where precise control over movement is critical.
• Packaging: Used in packaging lines, where it aids in the sorting, insertion, or placement of items in automated packaging systems. Its long stroke is beneficial for moving products or components through machines for processing or packaging.
• Robotics: The CDRQ2B 15 X 180 can be integrated into robotic systems where light-to-medium motion tasks are required. It can be used for gripping, sorting, lifting, or placing items, providing smooth linear motion for robotic arms.

5. Advantages:

• Compact yet Powerful: With a 15 mm bore and 180 mm stroke, this cylinder offers significant power in a compact design. This makes it ideal for use in applications with limited space, such as small automation systems or tight manufacturing setups.
• Extended Stroke for Versatility: The 180 mm stroke provides versatility for a wide range of applications that require longer travel distance, allowing for effective use in sorting, positioning, and handling tasks that need more travel.
• Energy Efficient: By using compressed air for both actions, the CDRQ2B 15 X 180 reduces energy consumption and operates more efficiently in environments with continuous or high-frequency motion.
• Durability: The high-quality materials used in the construction of this cylinder, such as aluminum and hardened steel, ensure its long lifespan and resistance to wear, even in high-cycle or harsh environments.
• Reliable Performance: The double-acting design ensures that the cylinder will perform consistently over time, even under high-cycle conditions, improving uptime and reducing maintenance costs.

6. Maintenance:

• Inspect Seals: Regular inspection of the cylinder's seals is recommended to prevent air leakage, which can reduce performance.
• Lubrication: Proper lubrication of the piston rod is crucial to reduce friction and wear, ensuring long service life.
• Check Mountings: Tighten any loose fasteners or brackets to prevent misalignment that could impact the cylinder’s operation.
• Clean Regularly: Keep the cylinder and piston rod clean to prevent dirt from entering the system, which could damage the seals and reduce cylinder lifespan.

7. Conclusion:

The Techno CDRQ2B 15 X 180 Pneumatic Cylinder is an ideal solution for moderate-force applications requiring longer travel distances. With a 15 mm bore and 180 mm stroke, this double-acting cylinder delivers precise, smooth, and reliable motion for material handling, automation systems, pressing, and robotics. Its compact design, durable construction, and energy efficiency make it a highly reliable and cost-effective solution for a wide range of industrial tasks.
