Techno CDRQ2B 20 X 90 Pneumatic Cylinder

The Techno CDRQ2B 20 X 90 Pneumatic Cylinder is a double-acting pneumatic actuator designed for precise and efficient linear motion in a variety of industrial applications. Featuring a 20 mm bore and a 90 mm stroke, this cylinder is ideal for applications that require moderate force and relatively short travel distance. It utilizes compressed air for both extension and retraction, ensuring smooth and controlled movement in both directions.

1. General Overview:

• Type: Pneumatic Cylinder (Double-Acting)
• Series: CDRQ2B
• Bore Size: 20 mm
• Stroke Length: 90 mm
• Action Type: Double-Acting
• Design: Built for precision, durability, and reliability in various industrial environments.

2. Detailed Breakdown of Specifications:

a. Bore Size (20 mm):

• The 20 mm bore is designed to deliver moderate force for applications that require light to medium-duty performance. It offers a compact solution for systems that need precision but are limited in space. Despite its smaller bore, it is capable of providing adequate force for tasks such as positioning, sorting, and pressing light-to-medium-weight components.

b. Stroke Length (90 mm):

• The 90 mm stroke provides moderate travel distance, making the cylinder suitable for applications where short, precise linear movement is needed. It is perfect for tasks requiring precise positioning, such as pick-and-place operations, sorting, or alignment tasks, as well as material handling in systems with limited space.

c. Double-Acting Cylinder (D):

• The double-acting design ensures that the cylinder uses compressed air for both extension and retraction, delivering smooth and controlled movement in both directions. This provides high efficiency in operations where both forward and backward motion is required, offering faster cycle times and reliable performance without the need for external retraction mechanisms.

3. Key Features and Benefits:

• Moderate Force Output: The 20 mm bore provides enough force for light-to-medium-duty applications while maintaining a compact form. This makes it an ideal solution for systems where space is limited but reliable, precise performance is still required.
• Short Travel Distance: The 90 mm stroke is perfect for applications that require short, controlled movement. It is well-suited for tasks that demand precise positioning within a limited range, such as in small robotic arms, automated assembly lines, or sorting systems.
• Double-Acting Design: The double-acting cylinder ensures smooth, efficient movement in both extension and retraction. This design eliminates the need for springs or other external mechanisms for retraction, increasing efficiency and reliability, especially in high-cycle environments.
• Durable Construction: Built with high-quality materials, the CDRQ2B 20 X 90 pneumatic cylinder features an anodized aluminum body and a hardened steel piston rod, ensuring resistance to wear and corrosion. This durability ensures a long service life in industrial environments.
• Energy Efficient: The cylinder's double-acting design makes it more energy-efficient by utilizing compressed air for both directions, ensuring reliable performance without excess air consumption, thus reducing operating costs.
• Compact Size: With its 20 mm bore and 90 mm stroke, this cylinder is highly compact and well-suited for tight spaces. It provides high performance without taking up valuable space, making it an ideal solution for integration into space-constrained systems.

4. Applications:

• Automation Systems: Ideal for use in automated material handling, pick-and-place operations, positioning, or sorting tasks in conveyor systems, robotic arms, and automated assembly lines.
• Material Handling: Perfect for tasks that involve moving, lifting, or positioning components in automated or semi-automated systems. Its short stroke and moderate force make it suitable for applications where precise control is required over small, lightweight materials.
• Pressing and Forming: Suitable for light pressing, alignment, or forming applications in industries such as electronics, automotive, or packaging, where high precision and controlled movement are essential.
• Packaging: Can be used for product positioning, sorting, or insertion in packaging systems, helping automate processes in environments like food processing, electronics, or consumer goods packaging.
• Robotics: Used in robotic arms or automated devices, this cylinder can handle precise, repeatable movements for applications such as gripping, lifting, or sorting tasks in robotic processes.

5. Advantages:

• Compact and Precise: The 20 mm bore and 90 mm stroke offer a compact design while still providing sufficient force for moderate-duty tasks. The short stroke allows for precise positioning and controlled motion over a smaller distance.
• Reliable Performance: The double-acting design ensures that the cylinder will provide reliable, consistent movement in both directions without relying on springs, reducing wear and increasing operational efficiency.
• Durable Construction: Made from high-quality materials, the cylinder's durable construction ensures long-term reliability even in high-cycle and demanding industrial applications.
• Energy Efficiency: The double-acting design allows the cylinder to optimize air consumption, leading to cost-effective and energy-efficient operation in industrial systems.
• Space-Saving Design: The compact size of the CDRQ2B 20 X 90 makes it perfect for installations in tight spaces, making it ideal for systems where space is a premium.

6. Maintenance:

• Inspect Seals: Regularly check the cylinder seals for wear or damage to prevent air leakage, which could decrease performance.
• Lubrication: Keep the piston rod properly lubricated to reduce friction and wear, extending the cylinder's lifespan.
• Check Fastenings: Ensure that the mounting bolts and other fastenings are securely tightened to avoid movement misalignment.
• Clean the Cylinder: Keep the cylinder body and piston rod clean to prevent dirt or debris from interfering with movement or damaging the seals.

7. Conclusion:

The Techno CDRQ2B 20 X 90 Pneumatic Cylinder is an ideal solution for light-to-medium-duty applications requiring precise and reliable linear motion in a compact form. With its 20 mm bore and 90 mm stroke, it delivers sufficient force for moderate tasks while maintaining a small footprint. The double-acting design ensures efficient and consistent performance, while the durable construction makes it suitable for long-term use in high-cycle industrial environments. Whether used in automation, material handling, or robotics, the CDRQ2B 20 X 90 offers reliable, energy-efficient operation.
