Techno CDRQ2B 40 X 90 Pneumatic Cylinder

The Techno CDRQ2B 40 X 90 Pneumatic Cylinder is a double-acting pneumatic actuator designed to provide powerful, precise, and reliable linear motion in a variety of industrial applications. Featuring a 40 mm bore and 90 mm stroke, this cylinder is ideal for tasks that require significant force and extended movement. It utilizes compressed air for both the extension and retraction strokes, making it highly efficient and capable of handling moderate-to-heavy-duty tasks.

1. General Overview:

• Type: Pneumatic cylinder (double-acting)
• Series: CDRQ2B
• Bore Size: 40 mm
• Stroke Length: 90 mm
• Action Type: Double-acting (D)
• Design: Robust, energy-efficient, and engineered for high performance in industrial environments.

2. Detailed Breakdown of Specifications:

a. Bore Size (40 mm):

• The 40 mm bore refers to the internal diameter of the cylinder’s chamber. A larger bore means the cylinder can generate greater force, making this pneumatic cylinder suitable for medium-to-heavy-duty applications. The 40 mm bore allows for higher force output, making it ideal for lifting, pressing, or heavy material handling.

b. Stroke Length (90 mm):

• The 90 mm stroke provides a substantial range of motion, enabling the cylinder to perform tasks that require significant movement. The relatively long stroke makes this cylinder suitable for positioning applications, pressing, or moving objects over a medium distance.

c. Double-Acting Cylinder (D):

• As a double-acting cylinder, the CDRQ2B 40 X 90 uses compressed air for both the extension and retraction strokes. This provides more precise control over movement and can generate more force compared to single-acting cylinders. The double-acting design ensures smooth, controlled motion in both directions, making it ideal for applications that require constant force or reliable return strokes.

3. Key Features and Benefits:

• Powerful Force Output: The 40 mm bore generates significant force, making the CDRQ2B 40 X 90 ideal for applications such as pressing, lifting, positioning heavy loads, or material handling.
• Long Stroke: With a 90 mm stroke, this cylinder provides greater flexibility in applications that require longer travel distances or more complex movements.
• Energy-Efficient: Like all pneumatic cylinders, the CDRQ2B 40 X 90 benefits from air-powered motion, offering cost-effective operation. The double-acting design ensures efficient use of compressed air for both extension and retraction.
• Durable Construction: Designed for high-cycle environments, this cylinder features robust materials like anodized aluminum for the body and hardened steel for the piston rod, providing long-lasting performance and resistance to wear and tear.
• Precise Control: The double-acting design offers precise and consistent control over the cylinder's movement, making it suitable for automated systems that require fine adjustments or repeatability in motion.
• Versatility: The CDRQ2B 40 X 90 offers a wide range of mounting options and can be adapted for various configurations, making it versatile and suitable for different applications.

4. Applications:

• Automation Systems: Used in pick-and-place operations, positioning of parts, or in assembly lines, where precise and repeatable movement is required.
• Material Handling: Perfect for lifting, moving, or positioning heavy objects in conveyor systems or sorting machines.
• Pressing and Forming: In industries like automotive or metalworking, this cylinder can be used for pressing or forming materials, where the higher force from the 40 mm bore is needed.
• Packaging: Ideal for use in packaging machinery for tasks such as product positioning, pressing, or inserting parts into packaging systems.
• Robotics: Ideal for robotic arms or automated devices requiring powerful, precise movements for tasks like pick-and-place, sorting, or assembly.

5. Advantages:

• Greater Force: The 40 mm bore delivers significant force output, making it ideal for tasks requiring heavy lifting, pressing, or material handling.
• Versatile Application: The 90 mm stroke provides the flexibility to handle a wide range of tasks, from small adjustments to long-range movements, making it versatile for various industrial applications.
• Smooth and Reliable Motion: The double-acting design ensures consistent, controlled movement with minimal maintenance, providing reliable operation even in demanding environments.
• Durable and Long-Lasting: Built to withstand high-cycle operations, the cylinder’s high-quality construction ensures durability and reliable long-term performance.
• Energy Efficiency: The double-acting design ensures that the cylinder performs efficiently with air on both the extension and retraction strokes, maximizing operational efficiency while reducing energy consumption.

6. Maintenance:

• Regular maintenance for the CDRQ2B 40 X 90 involves checking the seals for wear and inspecting the piston rod for any signs of damage. Leaks should be immediately addressed to prevent reduced efficiency.
• The air supply should be free from contaminants, and regular cleaning should be performed to prevent particles from affecting cylinder operation.
• Periodically check the mounting brackets and fasteners for proper alignment and secure attachment to ensure smooth operation.

7. Conclusion:

The Techno CDRQ2B 40 X 90 Pneumatic Cylinder is a powerful, double-acting actuator designed to provide reliable and precise linear motion in a wide variety of industrial applications. With a 40 mm bore and 90 mm stroke, it is suitable for medium-to-heavy-duty tasks such as lifting, pressing, material handling, and automated systems. The double-acting design ensures efficient operation with smooth, controlled movement in both directions. Built with durable materials and designed for high-cycle environments, this pneumatic cylinder offers long-lasting reliability and energy efficiency, making it an excellent choice for businesses looking to optimize performance while reducing maintenance and operational costs.
