Techno CRBU2-30 X 90 Pneumatic Cylinder

The Techno CRBU2-30 X 90 Pneumatic Cylinder is part of a series of pneumatic actuators designed for use in automated systems where controlled linear motion is required. Below is a detailed description of the product's key features and specifications:

1. Cylinder Type:

• CRBU2: The designation CRBU2 generally refers to a series of compact, double-acting pneumatic cylinders, commonly used in various industrial automation and motion control applications.
• This particular model is a double-acting cylinder, meaning it has ports at both ends to apply pressure for both forward and backward motion.
• The “2” in CRBU2 signifies a certain series type, often used to describe a specific range of pneumatic actuators.

2. Bore Size:

• 30 mm Bore (CRBU2-30): The bore size refers to the inner diameter of the cylinder's barrel. A bore size of 30 mm means the diameter of the piston inside the cylinder is 30 mm. This size dictates the force output of the cylinder, with larger bores generally providing higher force.

3. Stroke Length:

• 90 mm Stroke: The stroke length of 90 mm indicates the maximum distance the piston can travel within the cylinder from its fully retracted position to its fully extended position.

4. Operating Pressure:

• Pneumatic cylinders like the CRBU2-30 X 90 typically operate within a range of pressures. For most industrial cylinders, the operating pressure is around 1.5 to 10 bar (or 15-1000 kPa), though this depends on the specific model and manufacturer.

5. Materials and Construction:

• These cylinders are usually constructed from anodized aluminum for the barrel and stainless steel for the piston rod, ensuring durability and resistance to corrosion.
• Seals: High-quality seals are used to minimize air leakage and maintain efficiency, making the cylinders suitable for various industrial applications where precise motion control is required.

6. Mounting Style:

• Standard Mounting Options: The Techno CRBU2 series often offers multiple mounting styles such as foot, flange, or trunnion mounts, depending on the installation requirements.
• The mountings help to secure the cylinder in place during operation, ensuring stable and repeatable motion.

7. End-of-Stroke Cushions:

• The cylinder may include built-in cushioning at both ends, which helps reduce impact at the end of the stroke, prolonging the life of the cylinder and minimizing noise and vibration during operation.

8. Application Areas:

• These types of pneumatic cylinders are commonly used in automation, robotics, assembly lines, material handling, and any system that requires controlled linear movement.
• The CRBU2-30 X 90 is well-suited for use in environments where space is limited due to its compact design.

9. Pneumatic Connections:

• The cylinder will typically feature port threads (e.g., M5, G1/8, or NPT threads) for air supply connections, with both inlet and exhaust ports on either side of the cylinder to control the direction of motion.

10. Speed Control:

• Pneumatic cylinders like the CRBU2-30 X 90 often include the option for speed control valves, which allow users to fine-tune the velocity of the piston’s movement by regulating the airflow into and out of the cylinder.

11. Technical Specifications:

• Bore Size: 30 mm
• Stroke Length: 90 mm
• Max Operating Pressure: 10 bar (typical for such cylinders)
• Temperature Range: Typically, these cylinders can operate within a temperature range of about -10°C to 80°C, though this may vary based on the specific model.
• Seal Material: Often made of polyurethane or similar materials for durability.

12. Advantages of the CRBU2 Series:

• Compact and Space-saving Design: Ideal for installations in tight spaces without compromising on performance.
• High Durability: Thanks to its quality materials, this pneumatic cylinder is designed for long-term operation, even in demanding conditions.
• Versatile Mounting Options: A range of mounting styles makes it adaptable to different automation setups.

This cylinder is a great choice for industrial applications requiring high precision and reliable linear motion in a relatively compact form factor.
