Techno CXS10x100-S Pneumatic Cylinder Series

The Techno CXS10x100-S Pneumatic Cylinder Series is a double-acting pneumatic actuator designed to deliver precise linear motion over a 100 mm stroke with a 10 mm bore. This cylinder is engineered for applications where space is limited but high performance is required. It is ideal for systems that require compact yet powerful actuators such as automation, robotics, material handling, and packaging.

Product Overview:

The CXS10x100-S is a highly durable and reliable pneumatic cylinder designed for precise motion control. With its 10 mm bore and 100 mm stroke, this actuator is capable of providing smooth and consistent linear movement while maintaining high precision. Its double-acting design ensures that it operates effectively in both extension and retraction phases, making it highly versatile in applications requiring controlled motion in both directions.

Built with anodized aluminum for corrosion resistance and hardened steel for the piston rod, the CXS10x100-S is designed to perform well even in high-cycle and harsh environments. Additionally, it features high-performance seals that reduce friction and minimize air leakage, increasing energy efficiency and reducing the overall operational cost.

One of the key features of this series is the optional magnetic piston, which provides the ability to integrate position sensing into the cylinder, making it compatible with automated systems that require real-time position feedback for accurate control.

The CXS10x100-S operates within a pressure range of 1.5 to 8 bar, offering versatility for integration into various pneumatic control systems. This series is designed for minimal maintenance, ensuring reliable and cost-effective performance throughout its service life.

Key Features:

1. Compact and Efficient Design: The 10 mm bore and 100 mm stroke provide a compact solution for applications that require high precision and controlled movement without occupying excessive space.
2. Double-Acting Mechanism: The double-acting configuration ensures the cylinder works effectively in both extension and retraction phases, offering smooth, reliable motion in both directions.
3. Durable Construction: The anodized aluminum body ensures excellent corrosion resistance, while the hardened steel piston rod provides superior durability, even in high-cycle environments.
4. Energy Efficiency: The low-friction seals help reduce energy consumption by minimizing air leakage, making the CXS10x100-S a cost-effective and energy-efficient option for various applications.
5. Optional Magnetic Piston: The magnetic piston allows for the integration of position sensing capabilities, making the cylinder compatible with automated control systems that require accurate feedback on the position of the piston.
6. Versatile Pressure Range: The cylinder operates within a 1.5 to 8 bar pressure range, making it adaptable to different pneumatic systems and a variety of application needs.
7. Minimal Maintenance: With high-quality seals and durable materials, the CXS10x100-S requires minimal maintenance, reducing downtime and extending the lifespan of the actuator.
8. Flexible Mounting Options: The cylinder can be mounted using various configurations, including foot mounts, flange mounts, or custom options, providing flexibility in system design.

Applications:

The Techno CXS10x100-S Pneumatic Cylinder Series is ideal for a wide range of applications that require precise linear motion in compact spaces. Some typical applications include:

• Automation Systems: Used in automated production lines, robotic arms, and pick-and-place systems where accurate and repeatable motion is necessary.
• Material Handling: Suitable for conveyor systems, sorting systems, and automated transport systems, where precise, controlled motion is required in tight spaces.
• Packaging Machinery: Widely used in packaging systems for positioning materials, guiding products, or adjusting machine components accurately during packaging processes.
• Robotics: Ideal for robotic applications where small, controlled movements are required, such as in robotic arms, grippers, or positioning devices.
• Medical Equipment: The small form factor and precision make it ideal for use in medical devices that require accurate positioning in compact designs, such as in medical robots or diagnostic equipment.
• Textile and Printing Machines: Used in textile machinery and printing presses to adjust components, guide materials, or assist in positioning during the production process.

Performance Characteristics:

• Compact Force Output: The 10 mm bore delivers moderate force output, ideal for light to medium-duty applications where precise control and accuracy are more critical than high force.
• Precision and Repeatability: The 100 mm stroke ensures precise, repeatable motion, allowing for small adjustments and accurate control over the entire stroke length.
• Energy Efficiency: Low-friction seals and the minimal air leakage design contribute to reduced energy consumption, helping to lower the operational costs over time.
• Durability: The combination of hardened steel and anodized aluminum construction ensures the cylinder performs reliably even in high-cycle operations.

Specifications:

• Bore Size: 10 mm
• Stroke Length: 100 mm (customizable)
• Operating Pressure: 1.5 to 8 bar
• Materials: Anodized aluminum body, hardened steel piston rod, high-performance seals
• Magnetic Piston: Optional for position feedback
• Mounting Options: Foot, flange, and custom mounting configurations
• Temperature Range: Suitable for standard industrial environments

Advantages:

1. Compact and Efficient: The 10 mm bore and 100 mm stroke provide a compact solution for systems that require precise, repeatable motion in confined spaces.
2. Reliable Durability: Anodized aluminum and hardened steel construction ensures the cylinder is built to last, even in demanding industrial environments.
3. Energy-Efficient: Low-friction seals help minimize air leakage, resulting in a more energy-efficient operation that reduces operational costs.
4. Position Feedback: The optional magnetic piston adds position sensing capabilities, which is crucial for automated control systems and applications that require real-time position tracking.
5. Versatile Integration: The CXS10x100-S offers flexibility with multiple mounting options and the ability to integrate position sensors, making it suitable for a wide range of industrial applications.

Installation and Maintenance:

• Installation: The CXS10x100-S is easy to install, with foot mounts, flange mounts, and custom configurations available to suit various system designs.
• Maintenance: Thanks to the durable construction and high-quality seals, the cylinder requires minimal maintenance, reducing the frequency of repairs and the need for replacements.

Conclusion:

The Techno CXS10x100-S Pneumatic Cylinder Series is an ideal solution for applications requiring precise, repeatable linear motion in compact spaces. Offering a 100 mm stroke with a 10 mm bore, it combines compact size with high performance for use in automation, robotics, material handling, and packaging. With its durable materials, energy-efficient operation, and optional position sensing capabilities, the CXS10x100-S delivers reliable and cost-effective performance in a wide range of industrial applications, ensuring minimal maintenance and long-term operation.
