Techno MHZL2-20D Pneumatic Cylinder

The Techno MHZL2-20D Pneumatic Cylinder is a double-acting linear actuator designed for precision motion in a variety of industrial applications. Featuring a 20 mm bore size and stroke lengths ranging from 5 mm to 100 mm, this cylinder provides reliable and controlled movement for both light and medium-duty tasks. It is built to deliver efficient, repeatable motion in space-constrained environments, making it ideal for automation systems, robotics, material handling, and clamping applications.

Key Features:

1. Bore Size (20 mm):
   • The 20 mm bore size allows the cylinder to deliver moderate force while maintaining a compact design. It strikes a balance between providing the necessary output force for various tasks and fitting into tight spaces in automated systems and machinery.
2. Double-Acting Mechanism:
   • The double-acting design ensures that the cylinder can exert force in both extension and retraction directions, providing smooth and consistent motion. This design makes it suitable for repetitive tasks and precise adjustments in both directions.
3. Compact and Versatile Design:
   • The MHZL2-20D is designed with a compact body and a 20 mm bore size, which makes it ideal for applications that require controlled motion in limited spaces. Its size and force capabilities make it adaptable to various settings, whether it's a robotic arm, conveyor system, or clamping device.
4. Stroke Length:
   • The cylinder offers a stroke range of 5 mm to 100 mm, providing flexibility to suit different application requirements. Whether the task demands small adjustments or moderate travel distances, the MHZL2-20D can meet these needs with high precision.
5. Operating Pressure Range:
   • Operating efficiently within a pressure range of 1 to 8 bar, the cylinder is capable of producing a controlled force for various applications. This pressure range ensures that the cylinder performs effectively under normal operating conditions, offering both precision and power for light to medium-duty tasks.
6. Temperature Range:
   • The cylinder is designed to operate within a temperature range of -20°C to 80°C, ensuring it can perform in diverse environmental conditions, from cold to hot settings, making it versatile for a wide range of industrial processes.
7. Advanced Sealing Technology:
   • The MHZL2-20D is equipped with advanced sealing technology that minimizes air leakage and friction. This helps to maintain high efficiency, prevent unnecessary energy loss, and extend the operational lifespan of the cylinder.
8. Durable Construction:
   • Constructed from high-quality anodized aluminum and steel components, the cylinder is built to withstand harsh operating conditions. It is resistant to wear and corrosion, providing long-lasting, reliable performance even in demanding environments.
9. Mounting Options:
   • The MHZL2-20D comes with multiple mounting options, including foot mounts and flange mounts, offering flexibility for integration into various types of machinery and systems. This ensures easy installation in automated lines, robotic arms, positioning systems, or other equipment.
10. Adjustable Speed Control:
    • The cylinder offers adjustable speed control, allowing fine-tuning of the movement speed during both extension and retraction. This provides flexibility for applications requiring precise motion control and repeatability.

Applications:

• Automation Systems: The MHZL2-20D is ideal for use in automated manufacturing processes, such as sorting, positioning, and material handling, where accurate, controlled movements are necessary in compact spaces.
• Robotics: This cylinder is suitable for robotic applications that require precise movements and repeatable cycles. It can be used in tasks such as component placement, gripping, and adjusting parts.
• Material Handling: The MHZL2-20D is often used in material handling systems for applications like moving lightweight components, clamping, or positioning materials within production lines or packaging systems.
• Clamping Systems: The MHZL2-20D can be integrated into clamping systems to apply small yet precise forces for holding parts in place during assembly, processing, or machining operations.
• Positioning Systems: With its precision and adjustable stroke, the cylinder is an excellent choice for positioning systems that require repeatable, controlled movements to place parts or adjust equipment settings.
• Packaging Systems: The MHZL2-20D can also be used in packaging systems for tasks such as positioning packaging materials, adjusting products for labeling or packaging, and performing light handling tasks.

Advantages:

• Compact and Powerful: The 20 mm bore size delivers enough force for a variety of industrial tasks while maintaining a compact footprint, making it perfect for space-constrained environments.
• Precision and Control: The adjustable stroke length and double-acting design ensure precise, repeatable motion, providing reliable performance for both short and medium travel distances.
• Durable and Long-Lasting: The high-quality construction and advanced sealing technology ensure the cylinder’s longevity, reducing maintenance needs and providing consistent performance over time.
• Energy Efficiency: The advanced seals help minimize air leakage, improving energy efficiency and extending the operational life of the cylinder while reducing energy consumption.
• Flexible Integration: With its range of mounting options and adjustable speed controls, the MHZL2-20D is highly versatile and can be integrated into a wide range of automated systems, robotic setups, and industrial applications.

Conclusion:

The Techno MHZL2-20D Pneumatic Cylinder is a compact, double-acting actuator that combines precision, reliability, and flexibility. With a 20 mm bore size, a stroke range of 5 mm to 100 mm, and a pressure range of 1 to 8 bar, it offers the versatility to meet the needs of various automation systems, robotics, and material handling tasks. Its advanced sealing, energy-efficient design, and durable construction make it a top choice for demanding industrial environments, providing long-lasting, repeatable performance in tight spaces and across a variety of applications.
