Techno MSQB-20R Pneumatic Cylinder

The Techno MSQB-20R Pneumatic Cylinder is a high-performance, double-acting actuator with a 20 mm bore size designed for precise, reliable linear motion in various industrial applications. This cylinder is engineered for tasks that require medium to light force output, such as material handling, assembly, packaging, and robotic systems. Built for durability and versatility, the MSQB-20R offers smooth and controlled motion, optimizing operational efficiency in environments that demand precision, reliability, and minimal maintenance.

Key Features:

1. Bore Size (20 mm):
   • The 20 mm bore size of the MSQB-20R provides a balance between power and compact design. This makes it suitable for applications that need moderate force without occupying too much space. Its small profile allows it to fit into tight spaces, ideal for machines with space constraints.
2. Double-Acting Design:
   • The double-acting mechanism of the MSQB-20R ensures that compressed air powers both the extension and retraction of the piston. This design results in consistent, continuous motion, making the cylinder suitable for dynamic applications such as automated assembly lines and robotic arms.
3. Customizable Stroke Length:
   • The MSQB-20R can be tailored with a variety of stroke lengths to suit specific operational needs. Custom stroke lengths ensure that the cylinder can be optimized for applications requiring precise, controlled movements, whether it’s for pushing, pulling, or positioning.
4. Durable Construction:
   • Constructed from high-quality anodized aluminum and steel components, the MSQB-20R is designed to withstand harsh industrial environments. This robust construction ensures a long service life and reduces the likelihood of premature wear, making it a cost-effective choice for long-term operations.
5. Advanced Sealing Technology:
   • The MSQB-20R is equipped with advanced sealing technology to minimize air leakage, reduce friction, and enhance overall operational efficiency. This improves the cylinder’s performance and increases its lifespan by preventing contamination and air loss.
6. Pressure Range:
   • The cylinder operates within a pressure range of 2 to 8 bar, providing flexibility to suit a wide range of applications that require different force outputs. This flexibility is important for achieving the desired performance while optimizing energy consumption.
7. Temperature Range:
   • The MSQB-20R is designed to perform efficiently within a temperature range of -20°C to 80°C, making it versatile and able to handle both extreme cold and hot environments. This temperature flexibility ensures the cylinder remains reliable under diverse operating conditions.
8. Mounting Options:
   • The MSQB-20R offers multiple mounting options, such as foot mounts, flange mounts, and others, making it easy to integrate the cylinder into existing systems. The variety of mounting options ensures flexibility and ease of installation, adapting to various machine configurations.
9. Speed Control:
   • The MSQB-20R includes speed control features, allowing users to adjust the rate of extension and retraction. This ensures smooth and controlled operation, essential for applications requiring precise and consistent motion, such as automated assembly or robotic applications.
10. Compact Design:
    • Despite its ability to deliver moderate force, the MSQB-20R maintains a compact, space-efficient design. This allows it to be used in areas with limited space while still providing reliable force output for a wide range of applications.

Applications:

• Material Handling: The MSQB-20R is ideal for use in material handling systems, where it can be employed for pushing, pulling, sorting, and positioning tasks. Its small size and moderate force output make it perfect for automated production lines and conveyor systems.
• Assembly Lines: In assembly lines, the MSQB-20R can perform tasks such as part placement, alignment, and precise handling. Its customizable stroke length allows for flexibility in different setups and ensures accurate movement for assembly processes.
• Packaging Systems: The MSQB-20R is well-suited for packaging applications, where it can be used to sort, position, or seal products. Its reliable motion and compact design make it ideal for high-speed packaging lines that require precision and consistent operation.
• Clamping Systems: In clamping applications, the MSQB-20R can secure parts in place during processes like welding, machining, or assembly. Its robust construction ensures a tight grip, while its smooth retraction ensures safe and reliable part release.
• Robotic Systems: The MSQB-20R is an excellent choice for integration into robotic systems, where it can perform pick-and-place, sorting, and positioning tasks. Its double-acting design and speed control features ensure precise and efficient movement, essential for automation in robotics.
• Medical Equipment: In medical and laboratory settings, the MSQB-20R can be used in systems that require controlled motion for tasks such as sample handling, component assembly, and other precise operations. Its compact form and reliable performance make it suitable for applications in sensitive environments.

Advantages:

• Compact and Space-Saving: The MSQB-20R offers a small footprint, making it suitable for installations where space is at a premium. It delivers moderate force without taking up significant room, making it ideal for use in compact or space-constrained machinery.
• Reliable and Low Maintenance: Thanks to its advanced sealing system and durable construction, the MSQB-20R requires minimal maintenance while providing long-lasting performance. This reduces downtime and increases overall productivity, making it a cost-effective option for manufacturers.
• Customization: With customizable stroke lengths and mounting options, the MSQB-20R can be adapted to fit the specific requirements of various applications, ensuring optimal performance for each use case.
• Energy Efficiency: The MSQB-20R is designed to operate efficiently within the pressure range of 2 to 8 bar, helping to reduce air consumption and energy costs while still delivering reliable force output.
• Temperature and Pressure Flexibility: With a wide temperature range and flexible pressure capabilities, the MSQB-20R is suitable for use in a variety of industrial environments, from standard indoor conditions to more demanding applications in hot or cold settings.

Conclusion:

The Techno MSQB-20R Pneumatic Cylinder is a versatile, efficient, and reliable solution for medium to light-duty industrial applications. With its 20 mm bore size, double-acting design, and customizable stroke lengths, it excels in tasks such as material handling, assembly, clamping, packaging, and robotic automation. Its durable construction, advanced sealing technology, and speed control features ensure long-lasting, low-maintenance operation. Compact yet powerful, the MSQB-20R provides precise and efficient motion, making it an excellent choice for a wide range of industries requiring dependable pneumatic actuation.
